ISO 12127 Protective Clothing Heat Spread Testing Equipment
Introduction:
ISO 12127 Protective Clothing Heat Spread Testing Equipment for fire protection clothing is designed and manufactured according to ISO12127-2007 and EN702.
The ISO 12127 Protective Clothing Heat Spread Testing Equipment uses the heating cylinder to provide a constant temperature, while contacting with the sample under a certain load, and a calorimeter to measure the heat transfer properties. The instrument is easy to operate, the data is accurate and reliable, widely adopted in fire protective clothing companies and inspection departments.
Application:
Safety protection
Standard:
| ISO12127-2007 | Clothing for protection against heat and flame -- Determination of contact heat transmission through protective clothing or constituent materials |
| EN702 | Protective clothing. Protection against heat and flame. Test method. Determination of the contact heat transmission through protective clothing or its materials |
Specification:
| Product Name | ISO 12127 Protective Clothing Heat Spread Testing Equipment |
| This testing instrument | Consists of a control box and stainless steel test gantry |
| The sample holder is automatic lifting, lifting speed | 5mm ± 0.2mm/s |
| The K type sheathed thermocouples | Diameter 2mm, temperature measurement accuracy is 0.1 degree |
| Heating barrel temperature | Than 500 degree |
| The contact surface of the sample diameter | 25.2±0.05mm |
| Barrel heating load weight 49N | Adjustable |
| Timer scope | 0 to 99999s |
| timing accuracy | Up to 0.1s |
| Calorimeter fixed disk diameter | 25mm |
| Specimen diameter | 80m |
| Test table size | 650mm * 350 mm * 650mm |
| Power supply | 220V 50 / 60Hz, power 800w, can be customized |
| Weight | About 50 kg |
| Ambient Temperature | Operating25±5 degree |
| Gas Supplies requirement | Propane and air compressed air |
Product details:
